PTZ Keyboard Controller HK-C03N Connection Steps For Analog Speed Dome Cameras

2022-07-11

1.Connect the RS485 cable of the speed dome camera to the RS485 interface of the keyboard controller, be careful not to reverse the +/- poles of RS485

2.After connecting the RS485 cable, set the protocol of the controller to PELCO_D protocol , the Baud Rate value to 2400, and the camera address to 1.

3.After setting, exit to the main page to control
